2.3 Indications and controls
Table 3: Explanations of the indications and controls table columns
Column name Description
IEC 61850
name
Original IED data object identification. Described in the IEC 61850 format as
Logical Device.Logical Node and thereafter .Data Object.Data Attribute. Logical
Node is the same as the application function block name.
SA name The signal may have a defined label that is visible, for example, in the Application
Configuration tool in PCM600.
Description Short description of the signal. See the technical manual for more information.
DPI value IEC 60870-5-103 indication and control values are coded as two-bit values (= DPI).
10 = ON, 01 = OFF
FUN and INF Default function type and information number definition for the signal. Can be
modified via PCM600.
U Signal in use or not as default.
1 = In use, 0 = Not in use
Can be configured via PCM600.
ASDU ASDU type of the signal as default. ASDU type of indications can be modified via
PCM600. ASDU 1 and 2 are indications. ASDU 20 is control.
I General interrogation (GI) setting as default.
1 = In GI, 0 = Not in GI
Can be modified via PCM600.
C Extended DPI coding.
1 = Regular OFF/ON (01/10) values
2 = Four-pole INTERMEDIATE/OFF/ON/ERROR values (00/01/10/11)
2.3.1 General Data(FUN=0) IEC 60870-5-103 standard
Table 4: General Data(FUN=0) IEC 60870-5-103 standard
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.LNN0
.LEDRs1.ctlVal - LED reset 10=Reset 0 19 1 20 0 1
.Beh.stVal.(Test) - Test mode 10=On 0 21 1 1 1 1
LD0.I3CGGIO1
.ActSG.ctlVal/stVal - Param setting group 1 10=SG 1 0 23 1 1,20 1 1
.ActSG.ctlVal/stVal - Param setting group 2 10=SG 2 0 24 1 1,20 1 1
.ActSG.ctlVal/stVal - Param setting group 3 10=SG 3 0 25 1 1,20 1 1
.ActSG.ctlVal/stVal - Param setting group 4 10=SG 4 0 26 1 1,20 1 1
.ActSG.ctlVal/stVal - Param setting group 5 10=SG 5 0 27 1 1,20 1 1
.ActSG.ctlVal/stVal - Param setting group 6 10=SG 6 0 28 1 1,20 1 1
LD0.TCSSCBR1
.CirAlm.stVal ALARM Trip circuit 1 alarm 10=Alarm 0 36 1 1 1 1
LD0.LEDPTRC1
.Op.general - Global operate 10=Operate 0 68 1 2 0 1
.Str.general - Global start 10=Start 0 84 1 2 1 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
18 REM620
Point List Manual
