ABB 620 Series - LD0.PHPTOV1 Phase Overvoltage Protection - Stage 1; LD0.PHPTUV3 Phase Undervoltage Protection - Stage 3; LD0.PHPTUV2 Phase Undervoltage Protection - Stage 2

2.3.42 LD0.PHPTOV1 Phase overvoltage protection - stage 1
Table 45: LD0.PHPTOV1 Phase overvoltage protection - stage 1
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.PHPTOV1 Stage 1
.Str.phsA - -phsA start 10=Start 40 64 0 2 1 1
.Str.phsB - -phsB start 10=Start 40 65 0 2 1 1
.Str.phsC - -phsC start 10=Start 40 66 0 2 1 1
.Str.general START -general start 10=Start 40 84 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 40 90 1 2 0 1
2.3.43 LD0.PHPTUV3 Phase undervoltage protection - stage 3
Table 46: LD0.PHPTUV3 Phase undervoltage protection - stage 3
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.PHPTUV3 Stage 3
.Str.phsA - -phsA start 10=Start 41 44 0 2 1 1
.Str.phsB - -phsB start 10=Start 41 45 0 2 1 1
.Str.phsC - -phsC start 10=Start 41 46 0 2 1 1
.Str.general START -general start 10=Start 41 96 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 41 98 1 2 0 1
2.3.44 LD0.PHPTUV2 Phase undervoltage protection - stage 2
Table 47: LD0.PHPTUV2 Phase undervoltage protection - stage 2
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.PHPTUV2 Stage 2
.Str.phsA - -phsA start 10=Start 41 54 0 2 1 1
.Str.phsB - -phsB start 10=Start 41 55 0 2 1 1
.Str.phsC - -phsC start 10=Start 41 56 0 2 1 1
.Op.general OPERATE -general start 10=Operate 41 91 1 2 0 1
.Str.general START -general operate 10=Start 41 94 1 2 1 1
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 33
Point List Manual
