2.3.24 LD0.MAPGAPC4 Multipurpose analog protection function
(4)
Table 27: LD0.MAPGAPC4 Multipurpose analog protection function (4)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC4
.Str.general START Stage Start 10=Start 27 157 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 158 1 1 0 1
2.3.25 LD0.MAPGAPC5 Multipurpose analog protection function
(5)
Table 28: LD0.MAPGAPC5 Multipurpose analog protection function (5)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC5
.Str.general START Stage Start 10=Start 27 159 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 160 1 1 0 1
2.3.26 LD0.MAPGAPC6 Multipurpose analog protection function
(6)
Table 29: LD0.MAPGAPC6 Multipurpose analog protection function (6)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC6
.Str.general START Stage Start 10=Start 27 161 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 162 1 1 0 1
2.3.27 LD0.MAPGAPC7 Multipurpose analog protection function
(7)
Table 30: LD0.MAPGAPC7 Multipurpose analog protection function (7)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC7
.Str.general START Stage Start 10=Start 27 163 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 164 1 1 0 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
28 REM620
Point List Manual
