ABB 620 Series - LD0.SPCRGGIO1 Multipurpose Remote Binary Outputs (1); LD0.SEQRFUF1 Fuse Failure Protection

IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
.SPCS12.ctlVal - Output control 12 10/01=On/Off 11 212 1 1,20 0 1
.SPCS13.ctlVal - Output control 13 10/01=On/Off 11 213 1 1,20 0 1
.SPCS14.ctlVal - Output control 14 10/01=On/Off 11 214 1 1,20 0 1
.SPCS15.ctlVal - Output control 15 10/01=On/Off 11 215 1 1,20 0 1
.SPCS16.ctlVal - Output control 16 10/01=On/Off 11 216 1 1,20 0 1
2.3.12 LD0.SPCRGGIO1 Multipurpose remote binary outputs (1)
The binary outputs can be configured either as pulse- or persistent-type outputs. Pulse-
type outputs are triggered with the write value "ON". Persistent-type outputs can be
written with both values "ON" and "OFF". The setting mode "toggled" for local
operation corresponds to "persistent" for remote operation.
Table 15: LD0.SPCRGGIO1 Multipurpose remote binary outputs (1)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.SPCRGGIO1
.SPCS01.ctlVal - Output control 1 10/01=On/Off 11 221 1 1,20 0 1
.SPCS02.ctlVal - Output control 2 10/01=On/Off 11 222 1 1,20 0 1
.SPCS03.ctlVal - Output control 3 10/01=On/Off 11 223 1 1,20 0 1
.SPCS04.ctlVal - Output control 4 10/01=On/Off 11 224 1 1,20 0 1
.SPCS05.ctlVal - Output control 5 10/01=On/Off 11 225 1 1,20 0 1
.SPCS06.ctlVal - Output control 6 10/01=On/Off 11 226 1 1,20 0 1
.SPCS07.ctlVal - Output control 7 10/01=On/Off 11 227 1 1,20 0 1
.SPCS08.ctlVal - Output control 8 10/01=On/Off 11 228 1 1,20 0 1
.SPCS09.ctlVal - Output control 9 10/01=On/Off 11 229 1 1,20 0 1
.SPCS10.ctlVal - Output control 10 10/01=On/Off 11 230 1 1,20 0 1
.SPCS11.ctlVal - Output control 11 10/01=On/Off 11 231 1 1,20 0 1
.SPCS12.ctlVal - Output control 12 10/01=On/Off 11 232 1 1,20 0 1
.SPCS13.ctlVal - Output control 13 10/01=On/Off 11 233 1 1,20 0 1
.SPCS14.ctlVal - Output control 14 10/01=On/Off 11 234 1 1,20 0 1
.SPCS15.ctlVal - Output control 15 10/01=On/Off 11 235 1 1,20 0 1
.SPCS16.ctlVal - Output control 16 10/01=On/Off 11 236 1 1,20 0 1
2.3.13 LD0.SEQRFUF1 Fuse failure protection
Table 16: LD0.SEQRFUF1 Fuse failure protection
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.SEQRFUF1
.Str.general FUSEF_U General start 10=Start 22 84 1 2 1 1
.Str3Ph.general FUSEF_3PH 3 phase start 10=Start 22 94 1 2 1 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
24 REM620
Point List Manual
