2.3.68 LD0.ARCSARC1 Fault arc protection - stage 1
Table 71: LD0.ARCSARC1 Fault arc protection - stage 1
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.ARCSARC11
.FADet.stVal ARC_FLT_DE T Arc detected 10=Detect 156 211 1 1 0 1
LD0.ARCPTRC11
.Op.general OPERATE Operate 10=Operate 156 213 1 2 0 1
2.3.69 LD0.ARCSARC2 Fault arc protection - stage 2
Table 72: LD0.ARCSARC2 Fault arc protection - stage 2
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.ARCSARC21
.FADet.stVal ARC_FLT_DE T Arc detected 10=Detect 156 221 1 1 0 1
LD0.ARCPTRC21
.Op.general OPERATE Operate 10=Operate 156 223 1 2 0 1
2.3.70 LD0.ARCSARC3 Fault arc protection - stage 3
Table 73: LD0.ARCSARC3 Fault arc protection - stage 3
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.ARCSARC31
.FADet.stVal ARC_FLT_DE T Arc detected 10=Detect 156 231 1 1 0 1
LD0.ARCPTRC31
.Op.general OPERATE Operate 10=Operate 156 233 1 2 0 1
2.3.71 LD0.EFLPTOC1 Non-directional earth-fault and sensitive
earth-fault protection - low stage 1
Table 74: LD0.EFLPTOC1 Non-directional earth-fault and sensitive earth-fault protection - low stage 1
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.EFLPTOC1 Low (1) stage
.Str.general START -start 10=Start 159 84 1 2 1 1
.Op.general OPERATE -operate 10=Operate 159 90 1 2 0 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
40 REM620
Point List Manual
