2.3.14 CTRL.CCRDIF1 Current circuit failure protection
Table 17: CTRL.CCRDIF1 Current circuit failure protection
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
CTRL.CCRDIF1
.Alm.stVal ALARM Fail Alarm 10=Alarm 23 1 1 1 1 1
.Op.general FAIL Fail Operate 10=Operate 23 90 1 2 0 1
2.3.15 LD0.FRPFRQ1 Frequency protection (1)
Table 18: LD0.FRPFRQ1 Frequency protection (1)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.FRPTRC1
.Str.general START Stage start 10=Start 27 11 1 2 1 1
LD0.FRPTOF1 Overfrequency
.Op.general OPR_OFRQ -Operate 10=Operate 27 12 1 2 0 1
LD0.FRPTUF1 Underfrequency
.Op.general OPR_UFRQ -Operate 10=Operate 27 13 1 2 0 1
LD0.FRPFRC1 Frequency gradient
.Op.general OPR_FRG -Operate 10=Operate 27 14 1 2 0 1
2.3.16 LD0.FRPFRQ2 Frequency protection (2)
Table 19: LD0.FRPFRQ2 Frequency protection (2)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.FRPTRC2
.Str.general START Stage start 10=Start 27 21 1 2 1 1
LD0.FRPTOF2 Overfrequency
.Op.general OPR_OFRQ -Operate 10=Operate 27 22 1 2 0 1
LD0.FRPTUF2 Underfrequency
.Op.general OPR_UFRQ -Operate 10=Operate 27 23 1 2 0 1
LD0.FRPFRC2 Frequency gradient
.Op.general OPR_FRG -Operate 10=Operate 27 24 1 2 0 1
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 25
Point List Manual
