IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
.Q4.stVal - Input 4 signal 10=On 11 4 0 1 1 1
.Q5.stVal - Input 5 signal 10=On 11 5 0 1 1 1
.Q6.stVal - Input 6 signal 10=On 11 6 0 1 1 1
.Q7.stVal - Input 7 signal 10=On 11 7 0 1 1 1
.Q8.stVal - Input 8 signal 10=On 11 8 0 1 1 1
2.3.4 LD0.MVGAPC2 Multipurpose binary inputs (2)
Table 7: LD0.MVGAPC2 Multipurpose binary inputs (2)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MVGAPC2
.Q1.stVal - Input 1 signal 10=On 11 11 0 1 1 1
.Q2.stVal - Input 2 signal 10=On 11 12 0 1 1 1
.Q3.stVal - Input 3 signal 10=On 11 13 0 1 1 1
.Q4.stVal - Input 4 signal 10=On 11 14 0 1 1 1
.Q5.stVal - Input 5 signal 10=On 11 15 0 1 1 1
.Q6.stVal - Input 6 signal 10=On 11 16 0 1 1 1
.Q7.stVal - Input 7 signal 10=On 11 17 0 1 1 1
.Q8.stVal - Input 8 signal 10=On 11 18 0 1 1 1
2.3.5 LD0.MVGAPC3 Multipurpose binary inputs (3)
Table 8: LD0.MVGAPC3 Multipurpose binary inputs (3)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MVGAPC3
.Q1.stVal - Input 1 signal 10=On 11 21 0 1 1 1
.Q2.stVal - Input 2 signal 10=On 11 22 0 1 1 1
.Q3.stVal - Input 3 signal 10=On 11 23 0 1 1 1
.Q4.stVal - Input 4 signal 10=On 11 24 0 1 1 1
.Q5.stVal - Input 5 signal 10=On 11 25 0 1 1 1
.Q6.stVal - Input 6 signal 10=On 11 26 0 1 1 1
.Q7.stVal - Input 7 signal 10=On 11 27 0 1 1 1
.Q8.stVal - Input 8 signal 10=On 11 28 0 1 1 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
