2.3.2 General Data(FUN=10) - 620-specific
Table 5: General Data(FUN=10) - 620-specific
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.TRPPTRC1
.Op.general - Trip1 input 10=On 10 1 1 2 0 1
.Tr.general - Trip1 output 10=On 10 2 1 2 0 1
LD0.TRPPTRC2
.Op.general - Trip2 input 10=On 10 3 1 2 0 1
.Tr.general - Trip2 output 10=On 10 4 1 2 0 1
CTRL.LLN0
.Loc.stVal - Local/Remote state 10=Local 10 10 1 1 1 1
.LocRem.Station - Station state 10=On 10 11 1 1 1 1
LD0.LLN0
.LEDRs2.ctlVal - Reset alarm LEDs 10=Reset 10 21 1 20 0 1
.SetSeld.stVal - Param.setting reserved 10=Res 10 80 1 1 1 1
.SetChg.stVal - Param.setting changed 10=Chng 10 81 1 1 1 1
LD0.TCSSCBR2
.CirAlm.stVal ALARM Trip circuit 2 alarm 10=Alarm 10 36 1 1 1 1
DR.RDRE1
.RcdTrg.ctlVal - Trig DR recording 10=Trig 10 41 1 20 0 1
.MemClr.ctlVal - Clear DR memory 10=Clear 10 42 1 20 0 1
LD0.CMSTA1
.RecRs.ctlVal - Reset max.demands 1 10=Reset 10 45 1 20 0 1
LD0.LEDPTRC1 Global protection:
.Str.phsA - Start-phsA 10=Start 10 61 0 2 1 1
.Str.phsB - Start-phsB 10=Start 10 62 0 2 1 1
.Str.phsC - Start-phsC 10=Start 10 63 0 2 1 1
.Op.phsA - Operate-phsA 10=Operate 10 65 0 2 0 1
.Op.phsB - Operate-phsB 10=Operate 10 66 0 2 0 1
.Op.phsC - Operate-phsC 10=Operate 10 67 0 2 0 1
2.3.3 LD0.MVGAPC1 Multipurpose binary inputs (1)
Table 6: LD0.MVGAPC1 Multipurpose binary inputs (1)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MVGAPC1
.Q1.stVal - Input 1 signal 10=On 11 1 0 1 1 1
.Q2.stVal - Input 2 signal 10=On 11 2 0 1 1 1
.Q3.stVal - Input 3 signal 10=On 11 3 0 1 1 1
Table continues on next page
