2.3.39 LD0.DPHLPDOC1 Three-phase directional overcurrent
protection - low stage (1)
Table 42: LD0.DPHLPDOC1 Three-phase directional overcurrent protection - low stage (1)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.DPHLPTOC1 Low (1) stage
.Str.phsA - -phsA start 10=Start 32 64 0 2 1 1
.Str.phsB - -phsB start 10=Start 32 65 0 2 1 1
.Str.phsC - -phsC start 10=Start 32 66 0 2 1 1
.Str.general START -general start 10=Start 32 84 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 32 90 1 2 0 1
2.3.40 LD0.PHPTOV3 Phase overvoltage protection - stage 3
Table 43: LD0.PHPTOV3 Phase overvoltage protection - stage 3
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.PHPTOV3 Stage 3
.Str.phsA - -phsA start 10=Start 40 44 0 2 1 1
.Str.phsB - -phsB start 10=Start 40 45 0 2 1 1
.Str.phsC - -phsC start 10=Start 40 46 0 2 1 1
.Str.general START -general start 10=Start 40 96 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 40 98 1 2 0 1
2.3.41 LD0.PHPTOV2 Phase overvoltage protection - stage 2
Table 44: LD0.PHPTOV2 Phase overvoltage protection - stage 2
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.PHPTOV2 Stage 3
.Str.phsA - -phsA start 10=Start 40 54 0 2 1 1
.Str.phsB - -phsB start 10=Start 40 55 0 2 1 1
.Str.phsC - -phsC start 10=Start 40 56 0 2 1 1
.Op.general OPERATE -general operate 10=Start 40 91 1 2 0 1
.Str.general START -general start 10=Operate 40 94 1 2 1 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
32 REM620
Point List Manual
