2.3.55 LD0.XBGGIO115 Physical binary I/O signals (status only)
Table 58: LD0.XBGGIO115 Physical binary I/O signals (status only)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.XBGGIO115
.Ind1.stVal - XB115-Input 1 10/01=On/Off 50 21 0 1 1 1
.Ind2.stVal - XB115-Input 2 10/01=On/Off 50 22 0 1 1 1
.Ind3.stVal - XB115-Input 3 10/01=On/Off 50 23 0 1 1 1
.Ind4.stVal - XB115-Input 4 10/01=On/Off 50 24 0 1 1 1
.Ind5.stVal - XB115-Input 5 10/01=On/Off 50 25 0 1 1 1
.Ind6.stVal - XB115-Input 6 10/01=On/Off 50 26 0 1 1 1
.Ind7.stVal - XB115-Input 7 10/01=On/Off 50 27 0 1 1 1
.Ind8.stVal - XB115-Input 8 10/01=On/Off 50 28 0 1 1 1
.SPCSO1.stVal - XB115-Output 1 10/01=On/Off 50 121 0 1 1 1
.SPCSO2.stVal - XB115-Output 2 10/01=On/Off 50 122 0 1 1 1
.SPCSO3.stVal - XB115-Output 3 10/01=On/Off 50 123 0 1 1 1
.SPCSO4.stVal - XB115-Output 4 10/01=On/Off 50 124 0 1 1 1
2.3.56 LD0.MDSOPT1 Generic operation time supervision
Table 59: LD0.MDSOPT1 Generic operation time supervision
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MDSOPT1
.OpTmWrn.stVal WARNING Accum.op.time Warning 10=Warning 71 1 1 1 1 1
.OpTmAlm.stVal ALARM Accum.op.time Alarm 10=Alarm 71 2 1 1 1 1
2.3.57 LD0.MDSOPT2 Generic operation time supervision
Table 60: LD0.MDSOPT2 Generic operation time supervision
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MDSOPT2
.OpTmWrn.stVal WARNING Accum.op.time Warning 10=Warning 71 3 1 1 1 1
.OpTmAlm.stVal ALARM Accum.op.time Alarm 10=Alarm 71 4 1 1 1 1
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 37
Point List Manual
