ABB 620 Series - LD0.VMMXU1 Phase Voltage (1) Limit Supervision; LD0.RESVMMXU1 Residual Voltage (1) Limit Supervision; LD0.CMMXU2 Phase Currents (2) Limit Supervision; Ctrl.cxxxxx1 Circuit Breaker (1) CB Object and Failure Protection

2.3.80 LD0.VMMXU1 Phase voltage (1) limit supervision
Table 83: LD0.VMMXU1 Phase voltage (1) limit supervision
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.VMMXU1
.HiAlm.stVal HIGH_ALARM High alarm 10=Alarm 211 1 1 1 1 1
.HiWrn.stVal HIGH_WARN High warning 10=Warning 211 2 1 1 1 1
.LoWrn.stVal LOW_WARN Low warning 10=Warning 211 3 1 1 1 1
.LoAlm.stVal LOW_ALARM Low alarm 10=Alarm 211 4 1 1 1 1
2.3.81 LD0.RESVMMXU1 Residual voltage (1) limit supervision
Table 84: LD0.RESVMMXU1 Residual voltage (1) limit supervision
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.RESVMMXU1
.HiAlm.stVal HIGH_ALARM High alarm 10=Alarm 211 11 1 1 1 1
.HiWrn.stVal HIGH_WARN High warning 10=Warning 211 12 1 1 1 1
2.3.82 LD0.CMMXU2 Phase currents (2) limit supervision
Table 85: LD0.CMMXU2 Phase currents (2) limit supervision
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.CMMXU2
.HiAlm.stVal HIGH_ALARM High alarm 10=Alarm 212 1 0 1 1 1
.HiWrn.stVal HIGH_WARN High warning 10=Warning 212 2 0 1 1 1
.LoWrn.stVal LOW_WARN Low warning 10=Warning 212 3 0 1 1 1
.LoAlm.stVal LOW_ALARM Low alarm 10=Alarm 212 4 0 1 1 1
2.3.83 CTRL.Cxxxxx1 Circuit breaker (1) CB object and failure
protection
Table 86: CTRL.Cxxxxx1 Circuit breaker (1) CB object and failure protection
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
CTRL.CBCILO1
.EnaOpn.stVal ENA_OPEN Open enabled 10=Enabled 240 21 1 1 1 1
.EnaCls.stVal ENA_CLOSE Close enabled 10=Enabled 240 22 1 1 1 1
.ItlByPss.stVal ITL_BYPASS Interlocking bypass 10=Bypassed 240 25 0 1 1 1
CTRL.CBXCBR1
.BlkOpn.stVal BLK_OPEN Open blocked 10=Blocked 240 23 1 1 1 1
Table continues on next page
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 43
Point List Manual
