2.3.72 LD0.EFHPTOC1 Non-directional earth-fault and sensitive
earth-fault protection - high stage 1
Table 75: LD0.EFHPTOC1 Non-directional earth-fault and sensitive earth-fault protection - high stage 1
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.EFHPTOC1 High stage
.Str.general START -start 10=Start 159 96 1 2 1 1
.Op.general OPERATE -operate 10=Operate 159 98 1 2 0 1
2.3.73 LD0.EFIPTOC1 Non-directional earth-fault and sensitive
earth-fault protection - instantaneous stage 1
Table 76: LD0.EFIPTOC1 Non-directional earth-fault and sensitive earth-fault protection - instantaneous stage 1
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LDO.EFIPTOC1 Instantaneous stage
.Str.general START -start 10=Start 159 97 1 2 1 1
.Op.general OPERATE -operate 10=Operate 159 99 1 2 0 1
2.3.74 LD0.PHIPTOC1 Phase overcurrent protection -
instantaneous stage 1
Table 77: LD0.PHIPTOC1 Phase overcurrent protection - instantaneous stage 1
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.PHIPTOC1 Instantaneous stage (1)
.Str.phsA - -phsA start 10=Start 162 34 0 2 1 1
.Str.phsB - -phsB start 10=Start 162 35 0 2 1 1
.Str.phsC - -phsC start 10=Start 162 36 0 2 1 1
.Str.general START -general start 10=Start 162 97 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 162 99 1 2 0 1
2.3.75 LD0.PHLPTOC1 Phase overcurrent protection - low stage 1
Table 78: LD0.PHLPTOC1 Phase overcurrent protection - low stage 1
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.PHLPTOC1 Low stage (1)
.Str.phsA - -phsA start 10=Start 162 64 0 2 1 1
.Str.phsB - -phsB start 10=Start 162 65 0 2 1 1
.Str.phsC - -phsC start 10=Start 162 66 0 2 1 1
.Str.general START -general start 10=Start 162 84 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 162 90 1 2 0 1
