ABB 620 Series - Ctrl.cxxxxx2 Circuit Breaker (2) CB Object and Failure Protection; LD0.SSCBR1 Circuit Breaker (1) Condition Monitoring

IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
.BlkCls.stVal BLK_CLOSE Close blocked 10=Blocked 240 24 1 1 1 1
CTRL.CCBRBRF1
.Str.general CB_FAULT_AL Start, timer running 10=Start 240 101 0 2 1 1
.OpEx.general TRBU Failure, ext trip 10=Failure 240 102 0 2 0 1
.OpIn.general TRRET Operate, retrip 10=Operate 240 103 0 2 0 1
CTRL.CBCSWI1
.stSeld.stVal SELECTED CB selected 10=Selected 240 120 1 1 1 1
.Pos.stVal/ctlVal POSITION CB pos/control 10/01=Close/Open 240 160 1 1,20 1 2
2.3.84 CTRL.Cxxxxx2 Circuit breaker (2) CB object and failure
protection
Table 87: CTRL.Cxxxxx2 Circuit breaker (2) CB object and failure protection
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
CTRL.CBCILO2
.EnaOpn.stVal ENA_OPEN Open enabled 10=Enabled 240 26 1 1 1 1
.EnaCls.stVal ENA_CLOSE Close enabled 10=Enabled 240 27 1 1 1 1
.ItlByPss.stVal ITL_BYPASS Interlocking bypass 10=Bypassed 240 30 0 1 1 1
CTRL.CBXCBR2
.BlkOpn.stVal BLK_OPEN Open blocked 10=Blocked 240 28 1 1 1 1
.BlkCls.stVal BLK_CLOSE Close blocked 10=Blocked 240 29 1 1 1 1
CTRL.CCBRBRF2
.Str.general CB_FAULT_AL Start, timer running 10=Start 240 104 0 2 1 1
.OpEx.general TRBU Failure, ext trip 10=Failure 240 105 0 2 0 1
.OpIn.general TRRET Operate, retrip 10=Operate 240 106 0 2 0 1
CTRL.CBCSWI2
.stSeld.stVal SELECTED CB selected 10=Selected 240 121 1 1 1 1
.Pos.stVal/ctlVal POSITION CB pos/control 10/01=Close/Open 240 161 1 1,20 1 2
2.3.85 LD0.SSCBR1 Circuit breaker (1) condition monitoring
Table 88: LD0.SSCBR1 Circuit breaker (1) condition monitoring
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.SSCBR1
.RsAccAPwr.ctlVal RST_IPOW Accumul. energy reset 10=Reset 242 19 1 20 0 1
.RsCBWear.ctlVal RST_CB_WEAR CB life/op.counters reset 10=Reset 242 20 1 20 0 1
.RsTrvTm.ctlVal RST_TRV_T Travel time alarm reset 10=Reset 242 21 1 20 0 1
.RsSprChaTm.ctlVal RST_SPR_T Charge time alarm reset 10=Reset 242 22 1 20 0 1
.OpnAlm.stVal TRV_T_OP_ALM Opn travel time alarm 10=Alarm 242 101 0 1 0 1
Table continues on next page
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
44 REM620
Point List Manual
