2.3.98 CTRL.ESSXSWI2 Earth switch (2) - non-controllable object
Table 101: CTRL.ESSXSWI2 Earth switch (2) - non-controllable object
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
CTRL.ESSXSWI2
.Pos.stVal POSITION Earth switch pos 10/01=Close/Open 253 12 1 1 1 2
2.3.99 LD0.LEDGGIO1 LHMI LED indications Type 1 (2 states)
Table 102: LD0.LEDGGIO1 LHMI LED indications Type 1 (2 states)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.LEDGGIO1
.ISCSO1.stVal - LED 1 state 10=On 253 89 1 1 1 1
.ISCSO2.stVal - LED 2 state 10=On 253 90 1 1 1 1
.ISCSO3.stVal - LED 3 state 10=On 253 91 1 1 1 1
.ISCSO4.stVal - LED 4 state 10=On 253 92 1 1 1 1
.ISCSO5.stVal - LED 5 state 10=On 253 93 1 1 1 1
.ISCSO6.stVal - LED 6 state 10=On 253 94 1 1 1 1
.ISCSO7.stVal - LED 7 state 10=On 253 95 1 1 1 1
.ISCSO8.stVal - LED 8 state 10=On 253 96 1 1 1 1
.ISCSO9.stVal - LED 9 state 10=On 253 97 1 1 1 1
.ISCSO10.stVal - LED 10 state 10=On 253 98 1 1 1 1
.ISCSO11.stVal - LED 11 state 10=On 253 99 1 1 1 1
2.3.100 LD0.LEDGGIO1 LHMI LED indications Type 2 (3 states.
1:1 LED state)
Table 103: LD0.LEDGGIO1 LHMI LED indications Type 2 (3 states. 1:1 LED state)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.LEDGGIO1
.ISCSO1.stVal - LED 1 state
00/01/11=LED
State 253 119 1 1 0 2
.ISCSO2.stVal - LED 2 state
00/01/11=LED
State 253 120 1 1 0 2
.ISCSO3.stVal - LED 3 state
00/01/11=LED
State 253 121 1 1 0 2
.ISCSO4.stVal - LED 4 state
00/01/11=LED
State 253 122 1 1 0 2
.ISCSO5.stVal - LED 5 state
00/01/11=LED
State 253 123 1 1 0 2
.ISCSO6.stVal - LED 6 state
00/01/11=LED
State 253 124 1 1 0 2
Table continues on next page
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 49
