ABB 620 Series - LD0.SPCGGIO1 Multipurpose Binary Outputs (1); LD0.SPCGGIO2 Multipurpose Binary Outputs (2)

IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
.Rs6.ctlVal - Reset flip-flop 6 10=Reset 11 116 1 20 0 1
.Rs7.ctlVal - Reset flip-flop 7 10=Reset 11 117 1 20 0 1
.Rs8.ctlVal - Reset flip-flop 8 10=Reset 11 118 1 20 0 1
2.3.9 LD0.SPCGGIO1 Multipurpose binary outputs (1)
The binary outputs can be configured either as pulse- or persistent-type outputs. Pulse-
type outputs are triggered with the write value "ON". Persistent-type outputs can be
written with both values "ON" and "OFF". The setting mode "toggled" for local
operation corresponds to "persistent" for remote operation.
Table 12: LD0.SPCGGIO1 Multipurpose binary outputs (1)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.SPCGGIO1
.SPCS01.ctlVal - Output control 1 10/01=On/Off 11 141 1 20 0 1
.SPCS02.ctlVal - Output control 2 10/01=On/Off 11 142 1 20 0 1
.SPCS03.ctlVal - Output control 3 10/01=On/Off 11 143 1 20 0 1
.SPCS04.ctlVal - Output control 4 10/01=On/Off 11 144 1 20 0 1
.SPCS05.ctlVal - Output control 5 10/01=On/Off 11 145 1 20 0 1
.SPCS06.ctlVal - Output control 6 10/01=On/Off 11 146 1 20 0 1
.SPCS07.ctlVal - Output control 7 10/01=On/Off 11 147 1 20 0 1
.SPCS08.ctlVal - Output control 8 10/01=On/Off 11 148 1 20 0 1
.SPCS09.ctlVal - Output control 9 10/01=On/Off 11 149 1 20 0 1
.SPCS10.ctlVal - Output control 10 10/01=On/Off 11 150 1 20 0 1
.SPCS11.ctlVal - Output control 11 10/01=On/Off 11 151 1 20 0 1
.SPCS12.ctlVal - Output control 12 10/01=On/Off 11 152 1 20 0 1
.SPCS13.ctlVal - Output control 13 10/01=On/Off 11 153 1 20 0 1
.SPCS14.ctlVal - Output control 14 10/01=On/Off 11 154 1 20 0 1
.SPCS15.ctlVal - Output control 15 10/01=On/Off 11 155 1 20 0 1
.SPCS16.ctlVal - Output control 16 10/01=On/Off 11 156 1 20 0 1
2.3.10 LD0.SPCGGIO2 Multipurpose binary outputs (2)
The binary outputs can be configured either as pulse- or persistent-type outputs. Pulse-
type outputs are triggered with the write value "ON". Persistent-type outputs can be
written with both values "ON" and "OFF". The setting mode "toggled" for local
operation corresponds to "persistent" for remote operation.
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
22 REM620
Point List Manual
