2.3.76 LD0.DEFHPDEF1 Directional earth-fault protection - high
stage 1
Table 79: LD0.DEFHPDEF1 Directional earth-fault protection - high stage 1
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.DEFHPTOC1 High (1) stage
.Str.general START -start 10=Start 163 96 1 2 1 1
.Op.general OPERATE -operate 10=Operate 163 98 1 2 0 1
2.3.77 LD0.DEFLPDEF1 Directional earth-fault protection - low
stage 1
Table 80: LD0.DEFLPDEF1 Directional earth-fault protection - low stage 1
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.DEFLPTOC1 Low (1) stage
.Str.general START -start 10=Start 163 84 1 2 1 1
.Op.general OPERATE -operate 10=Operate 163 90 1 2 0 1
2.3.78 LD0.CMMXU1 Phase currents (1) limit supervision
Table 81: LD0.CMMXU1 Phase currents (1) limit supervision
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.CMMXU1
.HiAlm.stVal HIGH_ALARM High alarm 10=Alarm 210 1 1 1 1 1
.HiWrn.stVal HIGH_WARN High warning 10=Warning 210 2 1 1 1 1
.LoWrn.stVal LOW_WARN Low warning 10=Warning 210 3 1 1 1 1
.LoAlm.stVal LOW_ALARM Low alarm 10=Alarm 210 4 1 1 1 1
2.3.79 LD0.RESCMMXU1 Residual current (1) limit supervision
Table 82: LD0.RESCMMXU1 Residual current (1) limit supervision
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.RESCMMXU1
.HiAlm.stVal HIGH_ALARM High alarm 10=Alarm 210 11 0 1 1 1
.HiWrn.stVal HIGH_WARN High warning 10=Warning 210 12 0 1 1 1
