2.3.90 CTRL.DCXSWI4 Disconnector (4) - controllable object
Table 93: CTRL.DCXSWI4 Disconnector (4) - controllable object
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
CTRL.DCCILO4
.EnaOpn.stVal ENA_OPEN Open enabled 10=Enabled 246 31 1 1 1 1
.EnaCls.stVal ENA_CLOSE Close enabled 10=Enabled 246 32 1 1 1 1
.ItlByPss.stVal ITL_BYPASS Interlocking bypass 10=Bypassed 246 35 1 1 1 1
CTRL.DCXSWI4
.BlkOpn.stVal BLK_OPEN Open blocked 10=Blocked 246 33 1 1 1 1
.BlkCls.stVal BLK_CLOSE Close blocked 10=Blocked 246 34 1 1 1 1
CTRL.DCCSWI4
.stSeld.stVal SELECTED DC selected 10=Selected 246 122 1 1 1 1
.Pos.stVal/ctlVal POSITION DC pos/control 10/01=Close/Open 246 162 1 1,20 1 2
2.3.91 CTRL.ESXSWI1 Earth switch - controllable object
Table 94: CTRL.ESXSWI1 Earth switch - controllable object
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
CTRL.ESCILO1
.EnaOpn.stVal ENA_OPEN Open enabled 10=Enabled 247 21 1 1 1 1
.EnaCls.stVal ENA_CLOSE Close enabled 10=Enabled 247 22 1 1 1 1
.ItlByPss.stVal ITL_BYPASS Interlocking bypass 10=Bypassed 247 25 1 1 1 1
CTRL.ESXSWI1
.BlkOpn.stVal BLK_OPEN Open blocked 10=Blocked 247 23 1 1 1 1
.BlkCls.stVal BLK_CLOSE Close blocked 10=Blocked 247 24 1 1 1 1
CTRL.ESCSWI1
.stSeld.stVal SELECTED ES selected 10=Selected 247 120 1 1 1 1
.Pos.stVal/ctlVal POSITION ES pos/control 10/01=Close/Open 247 160 1 1,20 1 2
2.3.92 CTRL.ESXSWI2 Earth switch - controllable object
Table 95: CTRL.ESXSWI2 Earth switch - controllable object
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
CTRL.ESCILO2
.EnaOpn.stVal ENA_OPEN Open enabled 10=Enabled 247 26 1 1 1 1
.EnaCls.stVal ENA_CLOSE Close enabled 10=Enabled 247 27 1 1 1 1
.ItlByPss.stVal ITL_BYPASS Interlocking bypass 10=Bypassed 247 30 1 1 1 1
CTRL.ESXSWI2
.BlkOpn.stVal BLK_OPEN Open blocked 10=Blocked 247 28 1 1 1 1
Table continues on next page
