ABB 620 Series - LD0.FRPFRQ6 Frequency Protection (6); LD0.MAPGAPC1 Multipurpose Analog Protection Function (1); LD0.MAPGAPC2 Multipurpose Analog Protection Function (2); LD0.MAPGAPC3 Multipurpose Analog Protection Function (3)

2.3.20 LD0.FRPFRQ6 Frequency protection (6)
Table 23: LD0.FRPFRQ6 Frequency protection (6)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.FRPTRC6
.Str.general START Stage start 10=Start 27 61 1 2 1 1
LD0.FRPTOF6 Overfrequency
.Op.general OPR_OFRQ -Operate 10=Operate 27 62 1 2 0 1
LD0.FRPTUF6 Underfrequency
.Op.general OPR_UFRQ -Operate 10=Operate 27 63 1 2 0 1
LD0.FRPFRC6 Frequency gradient
.Op.general OPR_FRG -Operate 10=Operate 27 64 1 2 0 1
2.3.21 LD0.MAPGAPC1 Multipurpose analog protection function
(1)
Table 24: LD0.MAPGAPC1 Multipurpose analog protection function (1)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC1
.Str.general START Stage Start 10=Start 27 151 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 152 1 1 0 1
2.3.22 LD0.MAPGAPC2 Multipurpose analog protection function
(2)
Table 25: LD0.MAPGAPC2 Multipurpose analog protection function (2)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC2
.Str.general START Stage Start 10=Start 27 153 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 154 1 1 0 1
2.3.23 LD0.MAPGAPC3 Multipurpose analog protection function
(3)
Table 26: LD0.MAPGAPC3 Multipurpose analog protection function (3)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC3
.Str.general START Stage Start 10=Start 27 155 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 156 1 1 0 1
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 27
Point List Manual
