2.3.32 LD0.MAPGAPC12 Multipurpose analog protection function
(12)
Table 35: LD0.MAPGAPC12 Multipurpose analog protection function (12)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC12
.Str.general START Stage Start 10=Start 27 173 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 174 1 1 0 1
2.3.33 LD0.XRGGIO105 Alarm and warning
Table 36: LD0.XRGGIO105 Alarm and warning
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.XRGGIO105 XRGGIO105 Card
.Wrn.stVal WARNING -Warning 10=Warning 27 203 0 1 0 1
.Alm.stVal ALARM -Alarm 10=Alarm 27 204 0 1 0 1
2.3.34 LD0.XRGGIO110 Alarm and warning
Table 37: LD0.XRGGIO110 Alarm and warning
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.XRGGIO110 XRGGIO110 Card
.Wrn.stVal WARNING -Warning 10=Warning 27 205 0 1 0 1
.Alm.stVal ALARM -Alarm 10=Alarm 27 206 0 1 0 1
2.3.35 LD0.PSPTUV1 Positive-sequence undervoltage protection
- stage 1
Table 38: LD0.PSPTUV1 Positive-sequence undervoltage protection - stage 1
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.PSPTUV1 Stage 1
.Str.general START -general start 10=Start 42 84 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 42 90 1 2 0 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
30 REM620
Point List Manual
