ABB 620 Series - CTRL.DCXSWI2 Disconnector (2) - Controllable Object; CTRL.DCXSWI3 Disconnector (3) - Controllable Object

IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
.ItlByPss.stVal ITL_BYPASS Interlocking bypass 10=Bypassed 245 25 1 1 1 1
CTRL.DCXSWI1
.BlkOpn.stVal BLK_OPEN Open blocked 10=Blocked 245 23 1 1 1 1
.BlkCls.stVal BLK_CLOSE Close blocked 10=Blocked 245 24 1 1 1 1
CTRL.DCCSWI1
.stSeld.stVal SELECTED DC selected 10=Selected 245 120 1 1 1 1
.Pos.stVal/ctlVal POSITION DC pos/control 10/01=Close/Open 245 160 1 1,20 1 2
2.3.88 CTRL.DCXSWI2 Disconnector (2) - controllable object
Table 91: CTRL.DCXSWI2 Disconnector (2) - controllable object
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
CTRL.DCCILO2
.EnaOpn.stVal ENA_OPEN Open enabled 10=Enabled 246 21 1 1 1 1
.EnaCls.stVal ENA_CLOSE Close enabled 10=Enabled 246 22 1 1 1 1
.ItlByPss.stVal ITL_BYPASS Interlocking bypass 10=Bypassed 246 25 1 1 1 1
CTRL.DCXSWI2
.BlkOpn.stVal BLK_OPEN Open blocked 10=Blocked 246 23 1 1 1 1
.BlkCls.stVal BLK_CLOSE Close blocked 10=Blocked 246 24 1 1 1 1
CTRL.DCCSWI2
.stSeld.stVal SELECTED DC selected 10=Selected 246 120 1 1 1 1
.Pos.stVal/ctlVal POSITION DC pos/control 10/01=Close/Open 246 160 1 1,20 1 2
2.3.89 CTRL.DCXSWI3 Disconnector (3) - controllable object
Table 92: CTRL.DCXSWI3 Disconnector (3) - controllable object
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
CTRL.DCCILO3
.EnaOpn.stVal ENA_OPEN Open enabled 10=Enabled 246 26 1 1 1 1
.EnaCls.stVal ENA_CLOSE Close enabled 10=Enabled 246 27 1 1 1 1
.ItlByPss.stVal ITL_BYPASS Interlocking bypass 10=Bypassed 246 30 1 1 1 1
CTRL.DCXSWI3
.BlkOpn.stVal BLK_OPEN Open blocked 10=Blocked 246 28 1 1 1 1
.BlkCls.stVal BLK_CLOSE Close blocked 10=Blocked 246 29 1 1 1 1
CTRL.DCCSWI3
.stSeld.stVal SELECTED DC selected 10=Selected 246 121 1 1 1 1
.Pos.stVal/ctlVal POSITION DC pos/control 10/01=Close/Open 246 161 1 1,20 1 2
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
46 REM620
Point List Manual
