ABB 620 Series - Basic Application Functions; Miscellaneous

3.3.5 Basic application functions
⊠ Test mode
 Blocking of monitor direction
⊠ Disturbance data
 Generic services
⊠ Private data
3.3.6 Miscellaneous
Measurands are transmitted as Class2 data using ASDU 3 or ASDU 9. The default
MVAL scalings in this IED series is 2.4. The MVAL for each separate measurand
can be freely reprogrammed.
Measurand Max. MVAL = rated value times
1.2 or 2.4
Current L
1
⊠ ⊠
Current L
2
⊠ ⊠
Current L
3
⊠ ⊠
Voltage L
1-E
⊠ ⊠
Voltage L
2-E
⊠ ⊠
Voltage L
3-E
⊠ ⊠
Active power P ⊠ ⊠
Reactive power Q ⊠ ⊠
Frequency f ⊠ ⊠
Voltage L
1
- L
2
⊠ ⊠
The IED contains additional private Class2 frames, including private measurands.
User can freely select between standard or private Class2 frames.
If some required application data is not included in the
interoperability profile chapter, it does not necessarily mean that it
is missing from the IED. For example, the data is available in the
IED, but it does not create timetagged change events which are
required for Class1 data, or the data in the IED is not defined like in
the IEC 60870-5-103 standard. Map this missing data into generic
application object points using Application Configuration tool. The
protocol identification (function type, information number) for the
generic points can thereafter be freely modified by PCM600. Refer
to the point list for the outlook and default definitions of the generic
application object points.
