2.3.45 LD0.PHPTUV1 Phase undervoltage protection - stage 1
Table 48: LD0.PHPTUV1 Phase undervoltage protection - stage 1
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.PHPTUV1 Stage 1
.Str.phsA - -phsA start 10=Start 41 64 0 2 1 1
.Str.phsB - -phsB start 10=Start 41 65 0 2 1 1
.Str.phsC - -phsC start 10=Start 41 66 0 2 1 1
.Str.general START -general start 10=Start 41 84 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 41 90 1 2 0 1
2.3.46 LD0.NSPTOV1 Negative-sequence overvoltage protection
- stage 1
Table 49: LD0.NSPTOV1 Negative-sequence overvoltage protection - stage 1
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.NSPTOV1 Stage 1
.Str.general START -general start 10=Start 43 84 1 2 1 1
.Op.general OPERATE -general operate 10=Operate 43 90 1 2 0 1
2.3.47 LD0.NSPTOV2 Negative-sequence overvoltage protection
- stage 2
Table 50: LD0.NSPTOV2 Negative-sequence overvoltage protection - stage 2
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.NSPTOV2 Stage 2
.Str.phsA - -phsA start 10=Start 43 54 0 2 1 1
.Str.phsB - -phsB start 10=Start 43 55 0 2 1 1
.Str.phsC - -phsC start 10=Start 43 56 0 2 1 1
.Op.general OPERATE -general operate 10=Operate 43 91 1 2 0 1
.Str.general START -general start 10=Start 43 94 1 2 1 1
2.3.48 LD0.ROVPTOV1 Residual overvoltage protection - stage 1
Table 51: LD0.ROVPTOV1 Residual overvoltage protection - stage 1
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.ROVPTOV1
.Str.general START Stage 1 start 10=Start 44 84 1 2 1 1
.Op.general OPERATE Stage 1 operate 10=Operate 44 90 1 2 0 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
34 REM620
Point List Manual
