Table 13: LD0.SPCGGIO2 Multipurpose binary outputs (2)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.SPCGGIO2
.SPCS01.ctlVal - Output control 1 10/01=On/Off 11 181 1 1,20 0 1
.SPCS02.ctlVal - Output control 2 10/01=On/Off 11 182 1 1,20 0 1
.SPCS03.ctlVal - Output control 3 10/01=On/Off 11 183 1 1,20 0 1
.SPCS04.ctlVal - Output control 4 10/01=On/Off 11 184 1 1,20 0 1
.SPCS05.ctlVal - Output control 5 10/01=On/Off 11 185 1 1,20 0 1
.SPCS06.ctlVal - Output control 6 10/01=On/Off 11 186 1 1,20 0 1
.SPCS07.ctlVal - Output control 7 10/01=On/Off 11 187 1 1,20 0 1
.SPCS08.ctlVal - Output control 8 10/01=On/Off 11 188 1 1,20 0 1
.SPCS09.ctlVal - Output control 9 10/01=On/Off 11 189 1 1,20 0 1
.SPCS10.ctlVal - Output control 10 10/01=On/Off 11 190 1 1,20 0 1
.SPCS11.ctlVal - Output control 11 10/01=On/Off 11 191 1 1,20 0 1
.SPCS12.ctlVal - Output control 12 10/01=On/Off 11 192 1 1,20 0 1
.SPCS13.ctlVal - Output control 13 10/01=On/Off 11 193 1 1,20 0 1
.SPCS14.ctlVal - Output control 14 10/01=On/Off 11 194 1 1,20 0 1
.SPCS15.ctlVal - Output control 15 10/01=On/Off 11 195 1 1,20 0 1
.SPCS16.ctlVal - Output control 16 10/01=On/Off 11 196 1 1,20 0 1
2.3.11 LD0.SPCGGIO3 Multipurpose binary outputs (3)
The binary outputs can be configured either as pulse- or persistent-type outputs. Pulse-
type outputs are triggered with the write value "ON". Persistent-type outputs can be
written with both values "ON" and "OFF". The setting mode "toggled" for local
operation corresponds to "persistent" for remote operation.
Table 14: LD0.SPCGGIO3 Multipurpose binary outputs (3)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.SPCGGIO3
.SPCS01.ctlVal - Output control 1 10/01=On/Off 11 201 1 1,20 0 1
.SPCS02.ctlVal - Output control 2 10/01=On/Off 11 202 1 1,20 0 1
.SPCS03.ctlVal - Output control 3 10/01=On/Off 11 203 1 1,20 0 1
.SPCS04.ctlVal - Output control 4 10/01=On/Off 11 204 1 1,20 0 1
.SPCS05.ctlVal - Output control 5 10/01=On/Off 11 205 1 1,20 0 1
.SPCS06.ctlVal - Output control 6 10/01=On/Off 11 206 1 1,20 0 1
.SPCS07.ctlVal - Output control 7 10/01=On/Off 11 207 1 1,20 0 1
.SPCS08.ctlVal - Output control 8 10/01=On/Off 11 208 1 1,20 0 1
.SPCS09.ctlVal - Output control 9 10/01=On/Off 11 209 1 1,20 0 1
.SPCS10.ctlVal - Output control 10 10/01=On/Off 11 210 1 1,20 0 1
.SPCS11.ctlVal - Output control 11 10/01=On/Off 11 211 1 1,20 0 1
Table continues on next page
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 23
Point List Manual
