2.3.63 LD0.MPDIF1 Motor differential protection (1)
Table 66: LD0.MPDIF1 Motor differential protection (1)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MPDIF1
.Op.general OPERATE Stage Operate 10=Operate 28 51 1 1 0 1
2.3.64 LD0.MPTTR1 Motor thermal overload protection
Table 67: LD0.MPTTR1 Motor thermal overload protection
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MPTTR1
.StrInh.general BLK_RESTART Block restart 10=Restart 76 83 1 2 1 1
.AlmThm.general ALARM Thermal alarm 10=Alarm 76 85 1 2 1 1
.Op.general OPERATE Thermal operate 10=Operate 76 90 1 2 0 1
2.3.65 LD0.EMSGAPC1 Emergency start
Table 68: LD0.EMSGAPC1 Emergency start
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.EMSGAPC1
.Str.general ST_EMERG_ENA Emergency start 10=Start 77 84 1 2 1 1
2.3.66 LD0.LOFLPTUC1 Loss of load protection
Table 69: LD0.LOFLPTUC1 Loss of load protection
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.LOFLPTUC1
.Str.general START Stage start 10=Start 78 84 1 2 1 1
.Op.general OPERATE Stage operate 10=Operate 78 90 1 2 0 1
2.3.67 LD0.LOFLPTUC2 Loss of load protection
Table 70: LD0.LOFLPTUC2 Loss of load protection
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.LOFLPTUC2
.Str.general START Stage start 10=Start 78 94 1 2 1 1
.Op.general OPERATE Stage operate 10=Operate 78 91 1 2 0 1
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 39
Point List Manual
