ABB 620 Series - LD0.SSCBR2 Circuit Breaker (2) Condition Monitoring; CTRL.DCXSWI1 Disconnector (1) - Controllable Object

IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
.ClsAlm.stVal TRV_T_CL_ALM Cls travel time alarm 10=Alarm 242 102 0 1 0 1
.SprChaAlm.stVal SPR_CHR_ALM Spring charge time alarm 10=Alarm 242 103 0 1 0 1
.OpNumAlm.stVal OPR_ALM CB operations alarm 10=Alarm 242 104 0 1 0 1
.OpNumLO.stVal OPR_LO CB operations lockout 10=Lockout 242 105 0 1 0 1
.LonTmAlm.stVal MON_ALM CB inactive alarm 10=Alarm 242 106 0 1 0 1
.PresAlm.stVal PRES_ALM Low pressure alarm 10=Alarm 242 107 0 1 0 1
.PresLO.stVal PRES_LO Low pressure lockout 10=Lockout 242 108 0 1 0 1
.APwrAlm.stVal IPOW_ALM Iyt alarm 10=Alarm 242 109 0 1 0 1
.APwrLO.stVal IPOW_LO Iyt lockout 10=Lockout 242 110 0 1 0 1
.CBLifAlm.stVal CB_LIFE_ALM CB lifetime alarm 10=Alarm 242 111 0 1 0 1
2.3.86 LD0.SSCBR2 Circuit breaker (2) condition monitoring
Table 89: LD0.SSCBR1 Circuit breaker (2) condition monitoring
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.SSCBR2
.RsAccAPwr.ctlVal RST_IPOW Accumul. energy reset 10=Reset 243 19 1 20 0 1
.RsCBWear.ctlVal RST_CB_WEAR CB life/op.counters reset 10=Reset 243 20 1 20 0 1
.RsTrvTm.ctlVal RST_TRV_T Travel time alarm reset 10=Reset 243 21 1 20 0 1
.RsSprChaTm.ctlVal RST_SPR_T Charge time alarm reset 10=Reset 243 22 1 20 0 1
.OpnAlm.stVal TRV_T_OP_ALM Opn travel time alarm 10=Alarm 243 101 0 1 0 1
.ClsAlm.stVal TRV_T_CL_ALM Cls travel time alarm 10=Alarm 243 102 0 1 0 1
.SprChaAlm.stVal SPR_CHR_ALM Spring charge time alarm 10=Alarm 243 103 0 1 0 1
.OpNumAlm.stVal OPR_ALM CB operations alarm 10=Alarm 243 104 0 1 0 1
.OpNumLO.stVal OPR_LO CB operations lockout 10=Lockout 243 105 0 1 0 1
.LonTmAlm.stVal MON_ALM CB inactive alarm 10=Alarm 243 106 0 1 0 1
.PresAlm.stVal PRES_ALM Low pressure alarm 10=Alarm 243 107 0 1 0 1
.PresLO.stVal PRES_LO Low pressure lockout 10=Lockout 243 108 0 1 0 1
.APwrAlm.stVal IPOW_ALM Iyt alarm 10=Alarm 243 109 0 1 0 1
.APwrLO.stVal IPOW_LO Iyt lockout 10=Lockout 243 110 0 1 0 1
.CBLifAlm.stVal CB_LIFE_ALM CB lifetime alarm 10=Alarm 243 111 0 1 0 1
2.3.87 CTRL.DCXSWI1 Disconnector (1) - controllable object
Table 90: CTRL.DCXSWI1 Disconnector (1) - controllable object
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
CTRL.DCCILO1
.EnaOpn.stVal ENA_OPEN Open enabled 10=Enabled 245 21 1 1 1 1
.EnaCls.stVal ENA_CLOSE Close enabled 10=Enabled 245 22 1 1 1 1
Table continues on next page
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 45
Point List Manual
