IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
.BlkCls.stVal BLK_CLOSE Close blocked 10=Blocked 247 29 1 1 1 1
CTRL.ESCSWI2
.stSeld.stVal SELECTED ES selected 10=Selected 247 121 1 1 1 1
.Pos.stVal/ctlVal POSITION ES pos/control 10/01=Close/Open 247 161 1 1,20 1 2
2.3.93 CTRL.DCSXSWI1 Disconnector (1) - non-controllable object
Table 96: CTRL.DCSXSWI1 Disconnector (1) - non-controllable object
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
CTRL.DCSXSWI1
.Pos.stVal POSITION Disconnector 1 pos 10/01=Close/Open 253 1 1 1 1 2
2.3.94 CTRL.DCSXSWI2 Disconnector (2) - non-controllable object
Table 97: CTRL.DCSXSWI2 Disconnector (2) - non-controllable object
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
CTRL.DCSXSWI2
.Pos.stVal POSITION Disconnector 2 pos 10/01=Close/Open 253 2 1 1 1 2
2.3.95 CTRL.DCSXSWI3 Disconnector (3) - non-controllable object
Table 98: CTRL.DCSXSWI3 Disconnector (3) - non-controllable object
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
CTRL.DCSXSWI3
.Pos.stVal POSITION Disconnector 3 pos 10/01=Close/Open 253 3 1 1 1 2
2.3.96 CTRL.DCSXSWI4 Disconnector (4) - non-controllable object
Table 99: CTRL.DCSXSWI4 Disconnector (4) - non-controllable object
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
CTRL.DCSXSWI4
.Pos.stVal POSITION Disconnector 4pos 10/01=Close/Open 253 4 1 1 1 2
2.3.97 CTRL.ESSXSWI1 Earth switch (1) - non-controllable object
Table 100: CTRL.ESSXSWI1 Earth switch (1) - non-controllable object
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
CTRL.ESSXSWI1
.Pos.stVal POSITION Earth switch pos 10/01=Close/Open 253 11 1 1 1 2
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
48 REM620
Point List Manual
