IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
.ISCSO7.stVal - LED 7 state
00/01/11=LED
State 253 125 1 1 0 2
.ISCSO8.stVal - LED 8 state
00/01/11=LED
State 253 126 1 1 0 2
.ISCSO9.stVal - LED 9 state
00/01/11=LED
State 253 127 1 1 0 2
.ISCSO10.stVal - LED 10 state
00/01/11=LED
State 253 128 1 1 0 2
.ISCSO11.stVal - LED 11 state
00/01/11=LED
State 253 129 1 1 0 2
2.3.101 LD0.FKEYGGIO1 LHMI LED indications
Table 104: LD0.FKEYGGIO1 LHMI LED indications
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.FKEYGGIO1
.SPCS01.stVal - LED 1 state 10=On 253 131 1 1 1 1
.SPCS02.stVal - LED 2 state 10=On 253 132 1 1 1 1
.SPCS03.stVal - LED 3 state 10=On 253 133 1 1 1 1
.SPCS04.stVal - LED 4 state 10=On 253 134 1 1 1 1
.SPCS05.stVal - LED 5 state 10=On 253 135 1 1 1 1
.SPCS06.stVal - LED 6 state 10=On 253 136 1 1 1 1
.SPCS07.stVal - LED 7 state 10=On 253 137 1 1 1 1
.SPCS08.stVal - LED 8 state 10=On 253 138 1 1 1 1
.SPCS09.stVal - LED 9 state 10=On 253 139 1 1 1 1
.SPCS10.stVal - LED 10 state 10=On 253 140 1 1 1 1
.SPCS11.stVal - LED 11 state 10=On 253 141 1 1 1 1
.SPCS12.stVal LED 12 state 10=On 253 142 1 1 1 1
.SPCS13.stVal LED 13 state 10=On 253 143 1 1 1 1
.SPCS14.stVal LED 14 state 10=On 253 144 1 1 1 1
.SPCS15.stVal LED 15 state 10=On 253 145 1 1 1 1
.SPCS16.stVal LED 16 state 10=On 253 146 1 1 1 1
2.3.102 LD0.SECRSYN1 Synchrocheck indications
Table 105: LD0.SECRSYN1 Synchrocheck indications
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.SECRSYN1
.SynPrg.stVal SYNC_INPRO Synch in progress 10=Progress 26 1 1 1 1 1
.FailCmd.stVal CMD_FAIL_AL CB close req failed 10=Fail 26 2 1 1 0 1
.FailSyn.stVal CL_FAIL_AL CB close cmd failed 10=Fail 26 3 1 1 0 1
.EnSt.stVal ENERG_STATE Line and bus en.state Value 0…4 26 10 1 4 1 -
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
50 REM620
Point List Manual
