2.4.1 Class 2 private measurand data (6 and 7)
Class2 frames 6 and 7 are identical in this IED.
Table 107: Class 2 private measurand data (6 and 7)
IEC 61850 name Description Scale ix
LD0.CMMXU1 Phase currents (1)
LD0.CMMXU1 Phase-to-ground current
.A.phsA.cVal.mag -phsA magnitude 2.4 1
.A.phsB.cVal.mag -phsB magnitude 2.4 2
.A.phsC.cVal.mag -phsC magnitude 2.4 3
LD0.RESCMMXU1 Residual current (1)
LD0.RESCMMXU1 Residual current
.A.res.cVal.mag -magnitude 2.4 4
LD0.RESVMMXU1 Residual voltage (1)
LD0.RESVMMXU1 Residual voltage
.PhV.res.cVal.mag -magnitude 2.4 11
LD0.CSMSQI1 Sequence of currents (1)
LD0.CSMQI1 Sequence of currents
.SeqA.c1.cVal.mag -positive magnitude 2.4 12
.SeqA.c2.cVal.mag -negative magnitude 2.4 13
.SeqA.c3.cVal.mag -zero magitude 2.4 14
LD0.MPTTR1 Temperature of protected object (M)
LD0.MPTTR1
.TmpRl.mag Temperature 1000 22
LD0.CMSTA1 Demand currents (1)
LD0.CMSTA1 Phase-current demands
.AvAmpsA.mag -phsA magnitude 2.4 999
.AvAmpsB.mag -phsB magnitude 2.4 999
.AvAmpsC.mag -phsC magnitude 2.4 999
LD0.VMMXU1 Voltage measurands (1)
LD0.VMMXU1.phV Phase-to-ground voltage
.phsA.cVal.mag -phsA magnitude 2.4 5
.phsB.cVal.mag -phsB magnitude 2.4 6
.phsC.cVal.mag -phsC magnitude 2.4 7
LD0.VMMXU1.PPV Phase-to-phase voltage
.phsAB.cVal.mag -phsAB magnitude 2.4 8
.phsBC.cVal.mag -phsBC magnitude 2.4 9
.phsCA.cVal.mag -phsCA magnitude 2.4 10
