IEC 61850 name Description Scale ix
LD0.VSMSQI1 Sequence of voltages (1)
LD0.VSMSQI1 Sequence of voltages
.SeqA.c1.cVal.mag -positive magnitude 2.4 15
.SeqA.c2.cVal.mag -negative magnitude 2.4 16
.SeqA.c3.cVal.mag -zero magitude 2.4 17
LD0.PEMMXU1 Power measurands (1)
LD0.PEMMXU1
.TotW.instMag Active power P value 1000 18
.TotVAr.instMag Reactive power Q value 1000 19
.TotVA.instMag Apparent power S value 1000 20
.TotPF.instMag Power factor value 1 21
LD0.FMMXU1 Frequency measurement (1)
LD0.FMMXU1
.Hz.Mag Frequency value 100 23
LD0.XRGGIO110 RTD Input data
LD0.XRGGIO110
.AnIn1.mag RTD input 1 10000 999
.AnIn2.mag RTD input 2 10000 999
.AnIn3.mag RTD input 3 10000 999
.AnIn4.mag RTD input 4 10000 999
.AnIn5.mag RTD input 5 10000 999
.AnIn6.mag RTD input 6 10000 999
.AnIn7.mag RTD input 7 10000 999
.AnIn8.mag RTD input 8 10000 999
LD0.XRGGIO105 RTD Input data
LD0.XRGGIO105
.AnIn1.mag RTD input 1 10000 999
.AnIn2.mag RTD input 2 10000 999
.AnIn3.mag RTD input 3 10000 999
.AnIn4.mag RTD input 4 10000 999
.AnIn5.mag RTD input 5 10000 999
.AnIn6.mag RTD input 6 10000 999
.AnIn7.mag RTD input 7 10000 999
.AnIn8.mag RTD input 8 10000 999
