ABB 620 Series - LD0.ROVPTOV2 Residual Overvoltage Protection - Stage 2; LD0.ROVPTOV3 Residual Overvoltage Protection - Stage 3; LD0.XBGGIO105 Physical Binary I;O Signal (Status Only)

2.3.49 LD0.ROVPTOV2 Residual overvoltage protection - stage 2
Table 52: LD0.ROVPTOV2 Residual overvoltage protection - stage 2
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.ROVPTOV2
.Op.general OPERATE Stage 2 operate 10=Operate 44 91 1 2 0 1
.Str.general START Stage 2 start 10=Start 44 94 1 2 1 1
2.3.50 LD0.ROVPTOV3 Residual overvoltage protection - stage 3
Table 53: LD0.ROVPTOV3 Residual overvoltage protection - stage 3
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.ROVPTOV3
.Str.general START Stage 3 Start 10=Start 44 96 1 2 1 1
.Op.general OPERATE Stage 3 Operate 10=Operate 44 98 1 2 0 1
2.3.51 LD0.XBGGIO105 Physical binary I/O signal (status only)
Table 54: LD0.XBGGIO105 Physical binary I/O signal (status only)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.XBGGIO105
.Ind1.stVal - XB105-Input 1 10/01=On/Off 50 11 0 1 1 1
.Ind2.stVal - XB105-Input 2 10/01=On/Off 50 12 0 1 1 1
.Ind3.stVal - XB105-Input 3 10/01=On/Off 50 13 0 1 1 1
.Ind4.stVal - XB105-Input 4 10/01=On/Off 50 14 0 1 1 1
.Ind5.stVal - XB105-Input 5 10/01=On/Off 50 15 0 1 1 1
.Ind6.stVal - XB105-Input 6 10/01=On/Off 50 16 0 1 1 1
.Ind7.stVal - XB105-Input 7 10/01=On/Off 50 17 0 1 1 1
.Ind8.stVal - XB105-Input 8 10/01=On/Off 50 18 0 1 1 1
.SPCSO1.stVal - XB105-Output 1 10/01=On/Off 50 111 0 1 1 1
.SPCSO2.stVal - XB105-Output 2 10/01=On/Off 50 112 0 1 1 1
.SPCSO3.stVal - XB105-Output 3 10/01=On/Off 50 113 0 1 1 1
.SPCSO4.stVal - XB105-Output 4 10/01=On/Off 50 114 0 1 1 1
