2.3.58 LD0.MNSPTOC1 Negative-sequence overcurrent
protection for motors (1)
Table 61: LD0.MNSPTOC1 Negative-sequence overcurrent protection for motors (1)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MNSPTOC1
.Str.general START Stage1 start 10=Start 72 84 1 2 1 1
.Op.general OPERATE Stage1 operate 10=Operate 72 90 1 2 0 1
2.3.59 LD0.MNSPTOC2 Negative-sequence overcurrent
protection for motors (2)
Table 62: LD0.MNSPTOC2 Negative-sequence overcurrent protection for motors (2)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MNSPTOC2
.Str.general START Stage2 start 10=Start 72 94 1 2 1 1
.Op.general OPERATE Stage2 operate 10=Operate 72 91 1 2 0 1
2.3.60 LD0.JAMPTOC1 Stalled motor protection
Table 63: LD0.JAMPTOC1 Stalled motor protection
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.JAMPTOC1
.Op.general OPERATE Stalled operate 10=Operate 73 90 1 2 0 1
2.3.61 LD0.STTPMSU1 Motor startup supervision (1)
Table 64: LD0.STTPMSU1 Motor startup supervision (1)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.STTPMSU1
.Str.general MOT_START Motor start in progress 10=Startup 74 84 1 2 1 1
.Op.general OPR_IIT Thermal stress operate 10=Operate 74 90 1 2 0 1
2.3.62 LD0.PREVPTOC1 Phase reversal protection
Table 65: LD0.PREVPTOC1 Phase reversal protection
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.PREVPTOC1
.Str.general START Stage start 10=Start 75 84 1 2 1 1
.Op.general OPERATE Stage operate 10=Operate 75 90 1 2 0 1
Section 2 1MRS757657 A
IEC 60870-5-103 data mappings
38 REM620
Point List Manual
