ABB 620 Series - LD0.MAPGAPC8 Multipurpose Analog Protection Function (8); LD0.MAPGAPC9 Multipurpose Analog Protection Function (9); LD0.MAPGAPC10 Multipurpose Analog Protection Function (10); LD0.MAPGAPC11 Multipurpose Analog Protection Function (11)

2.3.28 LD0.MAPGAPC8 Multipurpose analog protection function
(8)
Table 31: LD0.MAPGAPC8 Multipurpose analog protection function (8)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC8
.Str.general START Stage Start 10=Start 27 165 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 166 1 1 0 1
2.3.29 LD0.MAPGAPC9 Multipurpose analog protection function
(9)
Table 32: LD0.MAPGAPC9 Multipurpose analog protection function (9)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC9
.Str.general START Stage Start 10=Start 27 167 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 168 1 1 0 1
2.3.30 LD0.MAPGAPC10 Multipurpose analog protection function
(10)
Table 33: LD0.MAPGAPC10 Multipurpose analog protection function (10)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC10
.Str.general START Stage Start 10=Start 27 169 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 170 1 1 0 1
2.3.31 LD0.MAPGAPC11 Multipurpose analog protection function
(11)
Table 34: LD0.MAPGAPC11 Multipurpose analog protection function (11)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.MAPGAPC11
.Str.general START Stage Start 10=Start 27 171 1 1 1 1
.Op.general OPERATE Stage Operate 10=Operate 27 172 1 1 0 1
1MRS757657 A Section 2
IEC 60870-5-103 data mappings
REM620 29
Point List Manual
