2.3.52 LD0.XHBGGIO105 Physical binary I/O signal (status only)
Table 55: LD0.XHBGGIO105 Physical binary I/O signal (status only)
IEC 61850 name SA name Description DPI value FUN INF U ASDU I C
LD0.XHBGGIO105
.Ind1.stVal - XHB105-Input 1 10/01=On/Off 50 31 0 1 1 1
.Ind2.stVal - XHB105-Input 2 10/01=On/Off 50 32 0 1 1 1
.Ind3.stVal - XHB105-Input 3 10/01=On/Off 50 33 0 1 1 1
.Ind4.stVal - XHB105-Input 4 10/01=On/Off 50 34 0 1 1 1
.Ind5.stVal - XHB105-Input 5 10/01=On/Off 50 35 0 1 1 1
.Ind6.stVal - XHB105-Input 6 10/01=On/Off 50 36 0 1 1 1
.Ind7.stVal - XHB105-Input 7 10/01=On/Off 50 37 0 1 1 1
.Ind8.stVal - XHB105-Input 8 10/01=On/Off 50 38 0 1 1 1
.SPCSO1.stVal - XHB105-Output 1 10/01=On/Off 50 131 0 1 1 1
.SPCSO2.stVal - XHB105-Output 2 10/01=On/Off 50 132 0 1 1 1
.SPCSO3.stVal - XHB105-Output 3 10/01=On/Off 50 133 0 1 1 1
2.3.53 LD0.XGGIO100 Physical binary I/O signals (status only)
Table 56: LD0.XGGIO100 Physical binary I/O signals (status only)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.XGGIO100
.SPCSO1.stVal - X100-Output 1 10/01=On/Off 53 101 0 1 1 1
.SPCSO2.stVal - X100-Output 2 10/01=On/Off 53 102 0 1 1 1
.SPCSO3.stVal - X100-Output 3 10/01=On/Off 53 103 0 1 1 1
.SPCSO4.stVal - X100-Output 4 10/01=On/Off 53 104 0 1 1 1
.SPCSO5.stVal - X100-Output 5 10/01=On/Off 53 105 0 1 1 1
.SPCSO6.stVal - X100-Output 6 10/01=On/Off 53 106 0 1 1 1
2.3.54 LD0.XAGGIO130 Physical binary I/O signals (status only)
Table 57: LD0.XAGGIO130 Physical binary I/O signals (status only)
IEC 61850 name
SA name Description DPI value FUN INF U ASDU I C
LD0.XAGGIO130
.Ind1.stVal - XA130-Input 1 10/01=On/Off 54 1 0 1 1 1
.Ind2.stVal - XA130-Input 2 10/01=On/Off 54 2 0 1 1 1
.Ind3.stVal - XA130-Input 3 10/01=On/Off 54 3 0 1 1 1
.Ind4.stVal - XA130-Input 4 10/01=On/Off 54 4 0 1 1 1
