ABB ACS880-104

Parameters 175
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 165). 2
MCW user bit 1 Bit 13 of 06.01 Main control word (see page 165). 3
MCW user bit 2 Bit 14 of 06.01 Main control word (see page 165). 4
MCW user bit 3 Bit 15 of 06.01 Main control word (see page 165). 5
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.43 LSU CW user bit 3
selection
(Only visible when supply unit control activated by 95.20)
Selects a binary source whose status is transmitted as bit 15
of 06.39 Internal state machine LSU CW to the supply unit.
MCW user bit
3
False 0. 0
True 1. 1
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 165). 2
MCW user bit 1 Bit 13 of 06.01 Main control word (see page 165). 3
MCW user bit 2 Bit 14 of 06.01 Main control word (see page 165). 4
MCW user bit 3 Bit 15 of 06.01 Main control word (see page 165). 5
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.45 Follower CW user
bit 0 selection
Selects a binary source whose status is transmitted as bit 12
of the Follower control word to follower drives. (Bits 0…11 of
the Follower control word are taken from 06.01 Main control
word.)
See also section Master/follower functionality (page 68).
MCW user bit
0
False 0. 0
True 1. 1
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 165). 2
MCW user bit 1 Bit 13 of 06.01 Main control word (see page 165). 3
MCW user bit 2 Bit 14 of 06.01 Main control word (see page 165). 4
MCW user bit 3 Bit 15 of 06.01 Main control word (see page 165). 5
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.46 Follower CW user
bit 1 selection
Selects a binary source whose status is transmitted as bit 13
of the Follower control word to follower drives. (Bits 0…11 of
the Follower control word are taken from 06.01 Main control
word.)
MCW user bit
1
False 0. 0
True 1. 1
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 165). 2
MCW user bit 1 Bit 13 of 06.01 Main control word (see page 165). 3
MCW user bit 2 Bit 14 of 06.01 Main control word (see page 165). 4
MCW user bit 3 Bit 15 of 06.01 Main control word (see page 165). 5
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.47 Follower CW user
bit 2 selection
Selects a binary source whose status is transmitted as bit 14
of the Follower control word to follower drives. (Bits 0…11 of
the Follower control word are taken from 06.01 Main control
word.)
MCW user bit
2
False 0. 0
True 1. 1
MCW user bit 0 Bit 12 of 06.01 Main control word (see page 165). 2
No. Name/Value Description Def
/FbEq16
