ABB ACS880-104

178 Parameters
True 1. 1
Torque control Bit 2 of 06.17 Drive status word 2 (see page 168). 2
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.71 User status word 1
bit 11 sel
Selects a binary source whose status is shown as bit 11 of
06.50 User status word 1.
Zero speed
False 0. 0
True 1. 1
Zero speed Bit 0 of 06.19 Speed control status word (see page 170). 2
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.72 User status word 1
bit 12 sel
Selects a binary source whose status is shown as bit 12 of
06.50 User status word 1.
Internal
speed
feedback
False 0. 0
True 1. 1
Internal speed
feedback
Bit 4 of 06.19 Speed control status word (see page 170). 2
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.73 User status word 1
bit 13 sel
Selects a binary source whose status is shown as bit 13 of
06.50 User status word 1.
False
False 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.74 User status word 1
bit 14 sel
Selects a binary source whose status is shown as bit 14 of
06.50 User status word 1.
False
False 0. 0
True 1. 1
Other [bit] Source selection (see Terms and abbreviations on page 148). -
06.75 User status word 1
bit 15 sel
Selects a binary source whose status is shown as bit 15 of
06.50 User status word 1.
False
False 0. 0
True 1. 1
Other [bit] Source selection (see
Terms and abbreviations on page 148). -
06.100 User control word 1 User-defined control word 1. -
0000h…FFFFh User-defined control word 1. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Description
0 User control word 1 bit 0 User-defined bit.
1 User control word 1 bit 1 User-defined bit.
…… …
15 User control word 1 bit 15 User-defined bit.
