Parameters 211
14.27 DIO4 ON delay (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Defines the activation delay for digital input/output DIO4. See
parameter 14.12 DIO1 ON delay.
0.00 s
0.00 … 3000.00 s Activation delay for DIO4. 10 = 1 s
14.27 AI1 scaled value (Visible when 14.01 Module 1 type = FIO-11 or FA I O - 0 1)
Displays the value of analog input AI1 after scaling. See
parameter 14.35 AI1 scaled at AI1 min.
This parameter is read-only.
-
-32768.000 …
32767.000
Scaled value of analog input AI1. 1 = 1
14.28 DIO4 OFF delay (Visible when 14.01 Module 1 type = FIO-01)
Defines the deactivation delay for digital input/output DIO4.
See parameter 14.12 DIO1 ON delay.
0.00 s
0.00 … 3000.00 s Deactivation delay for DIO4. 10 = 1 s
14.28 AI1 force data (Visible when 14.01 Module 1 type = FIO-11 or FA IO - 0 1)
Forced value that can be used instead of the true reading of
the input. See parameter 14.22 AI force selection.
0.000 mA
-22.000 … 22.000
mA or V
Forced value of analog input AI1. 1000 = 1 mA
or V
14.29 AI1 HW switch
position
(Visible when 14.01 Module 1 type = FIO-11 or FA IO-0 1)
Shows the position of the hardware current/voltage selector
on the I/O extension module.
Note: The setting of the current/voltage selector must match
the unit selection made in parameter 14.30 AI1 unit selection.
I/O module reboot either by cycling the power or through
parameter 96.08 Control board boot is required to validate
any changes in the hardware settings.
-
VVolts. 2
mA Milliamperes. 10
14.30 AI1 unit selection (Visible when 14.01 Module 1 type = FIO-11 or FA I O - 0 1)
Selects the unit for readings and settings related to analog
input AI1.
Note: This setting must match the corresponding hardware
setting on the I/O extension module (see the manual of the
I/O extension module). The hardware setting is shown by
parameter 14.29 AI1 HW switch position. I/O module reboot
either by cycling the power or through parameter 96.08
Control board boot is required to validate any changes in the
hardware settings.
mA
VVolts. 2
mA Milliamperes. 10
14.31 RO status (Visible when 14.01 Module 1 type = FIO-01 or FDIO-01)
Status of relay outputs on the I/O extension module.
Example: 0001b = RO1 is energized, RO2 is de-energized.
-
0000b…1111b Status of relay outpu ts. 1 = 1
14.31 AI1 filter gain (Visible when 14.01 Module 1 type = FIO-11 or FAIO - 0 1)
Selects a hardware filtering time for AI1.
See also parameter 14.32 AI1 filter time.
1 ms
No filtering No filtering. 0
125 us 125 microseconds. 1
No. Name/Value Description Def/FbEq16
