ABB ACS880-104

210 Parameters
AI3 max tune (Visible when 14.01 Module 1 type = FIO-11)
The measured value of AI3 is set as the maximum value of
AI3 into parameter 14.64 AI3 max.
6
14.22 DI3 ON delay (Visible when 14.01 Module 1 type = FDIO-01)
Defines the activation delay for digital input DI3. See
parameter 14.12 DI1 ON delay.
0.00 s
0.00 … 3000.00 s Activation delay for DI3. 10 = 1 s
14.22 DIO3 ON delay (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Defines the activation delay for digital input/output DIO3. See
parameter 14.12 DIO1 ON delay.
0.00 s
0.00 … 3000.00 s Activation delay for DIO3. 10 = 1 s
14.22 AI force selection (Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
The true readings of the analog inputs can be overridden for
eg. testing purposes. A forced value parameter is provided for
each analog input, and its value is applied whenever the
corresponding bit in this parameter is 1.
0000b
0000b…0111b Forced values selector for analog inputs. 1 = 1
14.23 DI3 OFF delay (Visible when 14.01 Module 1 type = FDIO-01)
Defines the deactivation delay for digital input DI3. See
parameter 14.12 DI1 ON delay.
0.00 s
0.00 … 3000.00 s Deactivation delay for DI3. 10 = 1 s
14.23 DIO3 OFF delay (Visible when 14.01 Module 1 type = FIO-01)
Defines the deactivation delay for digital input/output DIO3.
See parameter 14.12 DIO1 ON delay.
0.00 s
0.00 … 3000.00 s Deactivation delay for DIO3. 10 = 1 s
14.24 DIO4 function (Visible when 14.01 Module 1 type
= FIO-01)
Selects whether DIO4 of the extension module is used as a
digital input or output.
Input
Output DIO4 is used as a digital output. 0
Input DIO4 is used as a digital input. 1
14.26 DIO4 output source (Visible when 14.01 Module 1 type = FIO-01)
Selects a drive signal to be connected to digital input/output
DIO4 when parameter 14.24 DIO4 function is set to Output.
For the available selections, see parameter 14.11 DIO1
output source.
Not
energized
14.26 AI1 actual value (Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
Displays the value of analog input AI1 in mA or V (depending
on whether the input is set to current or voltage).
This parameter is read-only.
-
-22.000 … 22.000
mA or V
Value of analog input AI1. 1000 = 1 mA
or V
No. Name/Value Description Def/FbEq16
Bit Name Description
0 AI1 1 = Force mode: Force AI1 to value of parameter 14.28 AI1 force data.
1 AI2 1 = Force mode: Force AI2 to value of parameter 14.43 AI2 force data.
2 AI3 1 = Force mode: Force AI3 to value of parameter 14.58 AI3 force data
(FIO-11 only).
3…15 Reserved
