214 Parameters
14.38 RO2 ON delay (Visible when 14.01 Module 1 type = FIO-01 or FDIO-01)
Defines the activation delay for relay output RO2. See
parameter 14.35 RO1 ON delay.
0.00 s
0.00 … 3000.00 s Activation delay for RO2. 10 = 1 s
14.39 RO2 OFF delay (Visible when 14.01 Module 1 type = FIO-01 or FDIO-01)
Defines the deactivation delay for relay output RO2. See
parameter 14.35 RO1 ON delay.
0.00 s
0.00 … 3000.00 s Deactivation delay for RO2. 10 = 1 s
14.41 AI2 actual value (Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
Displays the value of analog input AI2 in mA or V (depending
on whether the input is set to current or voltage).
This parameter is read-only.
-
-22.000 … 22.000
mA or V
Value of analog input AI2. 1000 = 1 mA
or V
14.42 AI2 scaled value (Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
Displays the value of analog input AI2 after scaling. See
parameter 14.50 AI2 scaled at AI2 min.
This parameter is read-only.
-
-32768.000 …
32767.000
Scaled value of analog input AI2. 1 = 1
14.43 AI2 force data (Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
Forced value that can be used instead of the true reading of
the input. See parameter 14.22 AI force selection.
0.000 mA
-22.000 … 22.000
mA or V
Forced value of analog input AI2. 1000 = 1 mA
or V
14.44 AI2 HW switch
position
(Visible when 14.01
Module 1 type = FIO-11 or FAIO-01)
Shows the position of the hardware current/voltage selector
on the I/O extension module.
Note: The setting of the current/voltage selector must match
the unit selection made in parameter 14.45 AI2 unit selection.
I/O module reboot either by cycling the power or through
parameter 96.08 Control board boot is required to validate
any changes in the hardware settings.
-
VVolts. 2
mA Milliamperes. 10
14.45 AI2 unit selection (Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
Selects the unit for readings and settings related to analog
input AI2.
Note: This setting must match the corresponding hardware
setting on the I/O extension module (see the manual of the
I/O extension module). The hardware setting is shown by
parameter 14.44 AI2 HW switch position. I/O module reboot
either by cycling the power or through parameter 96.08
Control board boot is required to validate any changes in the
hardware settings.
mA
VVolts. 2
mA Milliamperes. 10
14.46 AI2 filter gain (Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
Selects a hardware filtering time for AI2.
See also parameter 14.47 AI2 filter time.
1 ms
No filtering No filtering. 0
No. Name/Value Description Def/FbEq16
