Parameters 313
32.06 Supervision 1
action
Selects the action the drive takes when the value monitored
by signal supervision 1 exceeds its limits.
Note: This parameter does not affect the status indicated by
32.01 Supervision status.
No action
No action No action taken. 0
Warning A warning (A8B0 Signal supervision) is generated. 1
Fault The drive trips on 80B0 Signal supervision.2
Fault if running If running, the drive trips on 80B0 Signal supervision.3
32.07 Supervision 1
signal
Selects the signal to be monitored by signal supervision
function 1.
Zero
Zero None. 0
Speed 01.01 Motor speed used (page 152). 1
Frequency 01.06 Output frequency (page 152). 3
Current 01.07 Motor current (page 152). 4
Torque 01.10 Motor torque (page 152). 6
DC voltage 01.11 DC voltage (page 152). 7
Output power 01.14 Output power (page 153). 8
AI1 12.11 AI1 actual value (page 197). 9
AI2 12.21 AI2 actual value (page 199). 10
Speed ref ramp in 23.01 Speed ref ramp input (page 257). 18
Speed ref ramp out 23.02 Speed ref ramp output (page
257). 19
Speed ref used 24.01 Used speed reference (page 263). 20
Torque ref used 26.02 Torque reference used (page 279). 21
Freq ref used 28.02 Frequency ref ramp output (page 285). 22
Process PID output 40.01 Process PID output actual (page 341). 24
Process PID
feedback
40.02 Process PID feedback actual (page 341). 25
Other Source selection (see Terms and abbreviations on page 148). -
32.08 Supervision 1 filter
time
Defines a filter time constant for the signal monitored by
signal supervision 1.
0.000 s
0.000 … 30.000 s Signal filter time. 1000 = 1 s
32.09 Supervision 1 low Defines the lower limit for signal supervision 1. 0.00
-21474830.00 …
21474830.00
Low limit. -
32.10 Supervision 1 high Defines the upper limit for signal supervision 1. 0.00
-21474830.00 …
21474830.00
Upper limit. -
32.15 Supervision 2
function
Selects the mode of signal supervision function 2. Determines
how the monitored signal (see parameter 32.17) is compared
to its lower and upper limits (32.19 and 32.20 respectively).
The action to be taken when the condition is fulfilled is
selected by 32.16.
Disabled
Disabled Signal supervision 2 not in use. 0
Low Action is taken whenever the signal falls below its lower limit. 1
No. Name/Value Description Def/FbEq16
