Parameters 351
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
40.50 Set 1 tracking ref
selection
Selects the value source for tracking mode. See parameter
40.49 Set 1 tracking mode.
Not selected
Not selected None. 0
AI1 scaled 12.12 AI1 scaled value (see page 197). 1
AI2 scaled 12.22 AI2 scaled value (see page 199). 2
FB A ref1 03.05 FB A reference 1 (see page 156). 3
FB A ref2 03.06 FB A reference 2 (see page 156). 4
Other Source selection (see Terms and abbreviations on page 148). -
40.51 Set 1 trim mode Activates the trim function and selects between direct and
proportional trimming (or a combination of both). With
trimming, it is possible to apply a corrective factor to the drive
reference (setpoint). The output after trimming is available as
parameter 40.05 Process PID trim output act.
See the control chain diagram on page 659.
Off
Off The trim function is inactive. 0
Direct The trim function is active. The trimming factor is relative to
the maximum speed, torque or frequency; the selection
between these is made by parameter 40.52 Set 1 trim
selection.
1
Proportional The trim function is active. The trimming factor is relative to
the reference selected by parameter 40.53 Set 1 trimmed ref
pointer.
2
Combined The trim function is active. The trimming factor is a
combination of both Direct and Proportional modes; the
proportions of each are defined by parameter 40.54 Set 1 trim
mix.
3
40.52 Set 1 trim selection Selects whether trimming is used for correcting the speed,
torque or frequency reference.
Torque
Torque Torque reference trimming. 1
Speed Speed reference trimming. 2
Frequency Frequency reference trimming. 3
40.53 Set 1 trimmed ref
pointer
Selects the signal source for the trim reference. Not selected
Not selected None. 0
AI1 scaled 12.12 AI1 scaled value (see page 197). 1
AI2 scaled 12.22 AI2 scaled value (see page 199). 2
FB A ref1 03.05 FB A reference 1 (see page 156). 3
FB A ref2 03.06 FB A reference 2 (see page 156). 4
Other Source selection (see Terms and abbreviations on page 148). -
No. Name/Value Description Def/FbEq16
