PREPARING FOR INSTALLATION
32 FOX615Installation
Figure 16: 11 HU adapter for the installation of the cable tray, subrack,
fan unit and heat deflection shield R7AI in ETSI racks (left
side adapter shown only)
44.5 mm
76.2 mm
190.5 mm
44.5 mm
31.7 mm
76.2 mm
12.7 mm
100.0 mm
175.0 mm
100.0 mm
75.0 mm
488.2 mm
1.5 mm
41.1 mm
4
3
2
1
