Disassembly/Assembly
Guidelines
IRB 6400
Page 1 - 8
Introduction
SYMBOLS USED IN THIS MANUAL
The symbols used throughout this manual are as follows:
EMERGENCY
This symbol warns you of dangers that can result in physical injury if great care
is not followed.
CAUTION
This symbol warns you of conditions that can result in damage to equipment if
care is not followed.
NOTE
This symbol calls your attention to added information worthy of your notation .
BULLET
The bullet is used to denote an item in a list of important items. It is also used
to denote a step in a list of important steps to follow to perform a procedure .
COMPONENT WEIGHT
The component weight box is used to give you a quick reference to the appro x-
imate weight of the component you are told to remove or lift. You can then
decide what equipment you need to assist you, if any.
E
E
C
MOTOR WEIGHS
APPROX. 50 LB.
