ABB PFEA 113 - Factory Default Settings

Tension Electronics PFEA113, User Manual
Section A.5 Factory Default Settings
3BSE029382R0101 Rev C A-11
A.5 Factory Default Settings
Table A-13. Factory Default Settings
Name PFEA113
Display language English
Display unit N
Load cell combination Two rolls
Gain scheduling No
Roll 1
• Object type Standard roll
• Load cell nominal load 1.0 kN 225 lbs
• Wrap gain 1
Roll 2
• Object type Standard roll
• Load cell nominal load 1.0 kN 225 lbs
• Wrap gain 1
AO1
• Function Current
• Connect signals A+B
• Filter settings 250 ms
• High tension 2000 N
• High output 20.00 mA
• Low tension 0 N
• Low output 4.00 mA
• High limit 21.00 mA
• Low limit 0.00 mA
AO2
• Function Current
• Connect signals C+D
• Filter settings 250 ms
• High tension 2000 N
• High output 20.00 mA
• Low tension 0 N
• Low output 4.00 mA
• High limit 21.00 mA
• Low limit 0.00 mA
