Tension Electronics PFEA113, User Manual
Appendix A Technical Data for Tension Electronics PFEA113
A-14 3BSE029382R0101 Rev C
A.6.2 Relay Board PXKB 201
The relay board PXKB 201 is intended to be installed on a DIN-rail 35 mm.
A.6.3 Power Supply Unit SD83x
The power supply unit is intended to be installed on a wall.
Table A-15. Data for Relay Board PXKB 201
Type Data
Input voltage 24 V DC
Connected to a digital output on
PFEA113
Typical input current 18 mA
Output voltage
Max connetion voltage
Min connection voltage
Should be connected to customers
superior system
250 V AC/DC
12 V AC/DC
Max continuous current 6 A
Ambient temperature -20 to +60 °C
Table A-16. Mains Supply Voltage
Data Remarks
Mains supply voltage 115 V AC (90 - 132 V),
100 V -10% to 120 V + 10%
230 V AC (180 - 264 V),
200 V -10% to 240 V + 10%
Auto-select
Table A-17. Power Supply Unit
Unit Dimensions (l x w x d) Weight
SD831 124 x 35x 102 mm 0.43 kg
SD832 124 x 35 x 117 mm 0.5 kg
SD833 124 x 60 x 117 mm 0,7 kg
