ABB PFEA 113 - 4.7 Operator Menus

Tension Electronics PFEA113, User Manual
Section 4.7 Operator Menus
3BSE029382R0101 Rev C 4-5
4.7 Operator Menus
This section describes the operator menus. The updating time for displayed values is 500 ms.
Use up and to switch between menus.
Figure 4-2. Operator Menus
TensionRoll 1
Value
Tension A
Value
Tension B
Value
TensionDiff A-B
Value
AO 1 - AO 6
Value
Error and
warning messages
TensionRoll 2
Value
Tension C
Value
Tension D
Value
TensionDiff C-D
Value
Tension values Roll 1
Tension values Roll 2
Tension values connected to AO1 - AO6
Value = N, kN, kg, lbs, N/m, kN/m, kg/m or pli
