ABB PFEA 113 - 3.12.4 Nominal Load

Tension Electronics PFEA113, User Manual
Section 3.12.4 Nominal Load
3BSE029382R0101 Rev C 3-21
3.12.4 Nominal Load
This section describes how to set nominal load for:
• One roll and Segmented roll
•Two rolls
Figure 3-11. Nominal Load Menus
The nominal load is selected from the list below and must be the same as the nominal load on
the load cell name plate. The load cell nominal load is displayed in kN and lbs on the same row.
The following nominal loads can be selected:
Table 3-1. Nominal Loads
[kN] [lbs]
0.1 22
0.2 45
0.5 112
1.0 225
2.0 450
5.0 1125
10 2250
20 4500
50 11250
100 22500
200 45000
FastSetUp
WebTension
Presentation-
Menu
SetNominal-
Load
ServiceMenu
ZeroSet
SetWrapGain
> 5 s
AO 1 - AO 6
Miscellaneous
Menu
System-
Definition
ObjectType
DO 1 - DO 4
AI 1 - AI 2
DI
NominalLoad
ZZ kN ZZ lbs
NominalLoad
[ZZ kN ZZ lbs]
Setting nominal load for One Roll and Segmented Roll
To ZeroSet
Roll 1
ZZ kN ZZ lbs
Roll 2
ZZ kN ZZ lbs
Roll 1
[ZZ kN ZZ lbs]
Roll 2
[ZZ kN ZZ lbs]
To ZeroSet
Setting nominal load for Two Rolls
SetNominalLoad
SetNominalLoad
