Appendix H Actual Data and Settings at Commissioning
H-2 3BSE029382R0101 Rev C
Analog Output 1 Off
Voltage
Current
Profibus only
Connect signals
Filter settings ms
High Tension
N, kN, kg, lbs,
N/m, kN/m, kg/m,
pli
High Output V, mA
Low Tension
N, kN, kg, lbs,
N/m, kN/m, kg/m,
pli
Low Output V, mA
High Limit V, mA
Low Limit V, mA
Analog Output 2 Off
Voltage
Current
Profibus only
Connect signals
Filter settings ms
High Tension
N, kN, kg, lbs,
N/m, kN/m, kg/m,
pli
High Output V, mA
Low Tension
N, kN, kg, lbs,
N/m, kN/m, kg/m,
pli
Low Output V, mA
High Limit V, mA
Low Limit V, mA
Analog Output 3 Off
Voltage
Current
Profibus only
Connect signals
Filter settings ms
High Tension
N, kN, kg, lbs,
N/m, kN/m, kg/m,
pli
High Output V, mA
Low Tension
N, kN, kg, lbs,
N/m, kN/m, kg/m,
pli
Low Output V, mA
High Limit V, mA
Low Limit V, mA
