Tension Electronics PFEA113, User Manual
Section 3.8.2 Performing Fast Setup using Wrap Gain
3BSE029382R0101 Rev C 3-9
13 Voltage selected:
Enter the tension value corresponding to 10 V.
or
Current selected:
Enter the tension value corresponding to 20 mA.
Confirm with .
14 Select filter setting (5, 15, 30, 75, 250, 750 or 1500 ms) from
the list with or . Confirm with .
15 FastSetUp of a system with one roll is now completed.
Press to finish the fast setup and go to the operator
menu.
Proceed with the FastSetUp for Roll 2. In step 4, select the
load cells (2, SingleSideC or SingleSideD) that support
Roll 2 from the list with or . Confirm with .
SetTensionAt10V
[XXXXXX] N
SetTensionAt20mA
[XXXXXX] N
FilterSettings
[250 ms 1.5Hz]
Finished
PressOk
To
Operator
Menu
