Tension Electronics PFEA113, User Manual
Section 3.11.1 Overview
3BSE029382R0101 Rev C 3-13
Select Voltage, Current or Profibus only
Connect AO1- AO6 to tension signals or a
combination of tension signals
Set filter settings
Set high tension value and high output voltage
Set low tension value and low output voltage
Set high and low output voltage limit
3.12.7
Set indication outputs for Level detectors 1-4
Set “Status OK” to indicate that the system is
running normally
3.12.8
Used to connect PFEA113 units to one another
when 2 or 3 are used.
- Set High Tension (N, kN, kg, lbs, N/m, kN/m,
kg/m, pli)
- High Input V
3.12.9
Can be used for:
- Zero set or
- Gain scheduling
3.12.10
Set Profibus address and measuring range
Reset all values to factory default
3.12.11
Read service information
Reset maximum load for load cell A
Reset maximum load for load cell B
Reset maximum load for load cell C
Reset maximum load for load cell D
3.12.12
