ABB Relion RER615 - LD0.DEFHPDEF1 Directional Earth-Fault Protection, High Stage (1); LD0.INTRPTEF1 Intermittent Earth Fault Protection (1); LD0.EFPADM1 Admittance-Based Earth-Fault Protection (1); LD0.EFPADM2 Admittance-Based Earth-Fault Protection (2)

2.3.13 LD0.DEFHPDEF1 Directional earth-fault protection, high
stage (1)
Table 16: LD0.DEFHPDEF1 Directional earth-fault protection, high stage (1)
BitA RegA IEC 61850 name SA name Description Values
LD0.DEFHPTOC1
2928 183.00 .Str.general START Stage start 1=Start
2929 183.01 .mcd
2930 183.02 .Op.general OPERATE Stage operate 1=Operate
2931 183.03 .mcd
2.3.14 LD0.INTRPTEF1 Intermittent earth fault protection (1)
Table 17: LD0.INTRPTEF1 Intermittent earth fault protection (1)
BitA RegA IEC 61850 name SA name Description Values
LD0.INTRPTEF1
3176 198.08 .Str.general START General Start 1=Start
3177 198.09 .mcd
3178 198.10 .Op.general OPERATE General Operate 2=Operate
3179 198.11 .mcd
2.3.15 LD0.EFPADM1 Admittance-based earth-fault protection (1)
Table 18: LD0.EFPADM1 Admittance-based earth-fault protection (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.EFPADM1
2840 177.08 .Str.general START Stage start 1=Start
2841 177.09 .mcd
2842 177.10 .Op.general OPERATE Stage operate 1=Operate
2843 177.11 .mcd
2.3.16 LD0.EFPADM2 Admittance-based earth-fault protection (2)
Table 19: LD0.EFPADM2 Admittance-based earth-fault protection (2)
BitA
RegA IEC 61850 name SA name Description Values
LD0.EFPADM2
2844 177.12 .Str.general START Stage start 1=Start
2845 177.13 .mcd
2846 177.14 .Op.general OPERATE Stage operate 1=Operate
2847 177.15 .mcd
1MRS757822 B Section 2
Modbus data mappings
Recloser Protection and Control RER615 23
Point List Manual
